SM8 SERIES LED MARKER - CLEAR, RED, AMBER
Description
The new SM8 LED Series markers are designed for the direct replacement of it's existing incandescent models. The SM8 series is made for heavy duty use which features a high impact acrylic lens and strong ABS base, and is suited to OEM and commercial vehicle applications.
Perfect for upgrading existing incandescent versions to LED.
Features
• 9-33 Volt DC integrated circuitry
• Clip mount
• Retro-fit same incandescent style lamp series
• 0.5m Cable
• Fully ADR compliant
FM8CLED SM8 Series LED front clearance marker (Clear) - 9-33V SM8ALED SM8 Series LED side marker (Amber) - 9-33V RM8RLED SM8 Series LED rear position marker (Red) - 9-33V
Specifications
Applications • Caravans • Trailers • Boat trailers • Light trucks Voltage 9-33V DC Varivolt®
Functions Front Clearance Marker: Clear
Side Marker: Amber
Rear Position Marker: Red Wattage 0.8W - all functions Mounting
Clip mount Materials
High impact acrylic lens Environmental
IP67 Hermetically Sealed Cable Length 0.5M Standard
Dimensions 90x50x22mm ADR Compliance
Front Clearance Marker: 49/01, Reflector 47/00
Side Marker: 45/01, Reflector 47/00
Rear Position Marker: 49/00, Reflector 47/00 Homologation Certification
E-Mark
CRN
Pending
