• Ideal for camper and work trailers that need a strong swing away unit.
• The 60mmØ Jockey unit is adjustable in swing away bracket to gain extra height if required.
• Patented BOS® Gearbox features a unique 12mm drive set for added security and provides effortless operation with a cordless drill or manual handle as a backup.
• Load Capacity of up to 500kg.
• 280mm Extended travel.
• The articulated base plate kit will adjust to uneven ground up to 30º and is great if you have no need for a wheel.
• Unique patented BOS® PUSH/PULL Handle makes release & rotation easy.
• Will fit Draw Bars (chassis) from 100-150mm (4”-6”) High x 50mm (2’’) Wide.
• 120mm Pipe extension when extra height is needed.

OPTIONAL ACCESSORIES:

200-060 8″ Double Offset Wheel (Sold Separately).

020-009 M12X65 Security Screw & Key

• PATENTED BOS® GEARBOX Allows effortless operation using a drill and the option to use manual handle with ease.
• 12MM INPUT (NOT 1/2”) Unique size for added security.
• WELDED LUGS For adjustable height.
• BOS® FIRST TO USE STAINLESS STEEL INNER PIPE 48MM Reduced down to 42mm 3.5mm wall thickness.
• BOS® WORLD FIRST ARTICULATED BASE PLATE Unique ball joint design is great for uneven ground up to 30º.
• GREASE NIPPLE Provides grease to bearing, thread & gearbox.
• PREMIUM TEXTURED BLACK POWDER COATED CNC Machined outer pipe from heavy walled pipe.
• GUIDE BUSH For rigidity of the inner pipe.
• INNER PIPE LOCK Rebate to lock the inner pipe to prevent unwinding when travelling.
• BOS® MOUNTING SYSTEM Suits 100-150mm frame in height x 50mm wide.
• BOS® PATENTED RED PUSH/PULL HANDLE Unique design that allows you to push or pull from either end of the handle.
• BOS® HEAVY DUTY SWING AWAY CLAMPING BRACKET Fold away handle allows easy tightening or loosening to adjust the jockey height.
